Data privacy is the single biggest hurdle for companies looking to adopt generative AI assistants. Sending proprietary code, financial records, or customer data to commercial APIs exposes organizations to severe data leakage risks and compliance violations.
The solution is self-hosting. By deploying an open-source chatbot interface and routing traffic through a local API gateway, you can create a private, secure, enterprise-grade ChatGPT alternative.
This tutorial walks through deploying the industry-standard open-source stack: LibreChat (the frontend UI), LiteLLM (the routing and proxy gateway), and MongoDB (conversational history storage) using Docker Compose.
The Self-Hosted AI Stack Architecture
Before looking at code, let’s analyze how data flows in this architecture:
graph TD
User([User Web Browser]) <-->|HTTPS| LibreChat[LibreChat UI]
LibreChat <-->|Save History| MongoDB[(Local MongoDB)]
LibreChat <-->|OpenAI SDK Protocol| LiteLLM{LiteLLM API Gateway}
LiteLLM <-->|Local Network| Ollama[Local Ollama / vLLM CPU]
LiteLLM <-->|Internet| Gemini[Google Gemini API]
LiteLLM <-->|Internet| OpenAI[OpenAI API]
- LibreChat: Provides a modern, ChatGPT-like interface supporting multi-user authentication, file attachments, search, and custom agent presets.
- MongoDB: Statically stores conversation histories, settings, and user profiles locally.
- LiteLLM: Standardizes API calls. Whether routing to a local model running on Ollama or a remote model on Vertex AI, LiteLLM presents a unified, OpenAI-compatible API to LibreChat.
Step 1: Create the Directory Structure
Create a new directory for your project and initialize the configuration files:
mkdir self-hosted-chatbot && cd self-hosted-chatbot
touch docker-compose.yml config.yaml librechat.yaml .env
Step 2: Configure LiteLLM (config.yaml)
config.yaml tells LiteLLM which models are available and how to route traffic. In this configuration, we expose a local Llama 3 model running on Ollama and route commercial APIs (Gemini & OpenAI) securely:
model_list:
# 1. Local Model via Ollama
- model_name: local-llama3
litellm_params:
model: ollama/llama3
api_base: http://host.docker.internal:11434
tpm: 100000
rpm: 1000
# 2. Google Gemini Flash
- model_name: gemini-3.5-flash
litellm_params:
model: gemini/gemini-1.5-flash
api_key: os.environ/GEMINI_API_KEY
# 3. OpenAI GPT-4.1
- model_name: gpt-4.1-nano
litellm_params:
model: gpt-4.1-nano
api_key: os.environ/OPENAI_API_KEY
router_settings:
routing_strategy: usage-based-routing-v2
enable_fallbacks: true
host.docker.internal: Allows the containerized LiteLLM instance to access an Ollama server running locally on the host machine.os.environ/...: LiteLLM pulls sensitive API keys directly from Docker environment variables, keeping configurations secure.
Step 3: Configure LibreChat (librechat.yaml)
We configure LibreChat to communicate with LiteLLM as a custom endpoint. This maps all models declared in LiteLLM directly to LibreChat’s interface:
# librechat.yaml
version: 1.1.0
# Configure Custom Endpoints
endpoints:
custom:
- name: "LiteLLM Gateway"
apiKey: "sk-litellm-dummy-key"
baseURL: "http://litellm:4000/v1"
models:
default: ["local-llama3", "gemini-3.5-flash", "gpt-4.1-nano"]
fetch: false
titleConvo: true
titleModel: "gemini-3.5-flash"
summarize: true
convoTokenLimit: 4096
# Disable other built-in direct endpoints to force LiteLLM routing
interface:
endpointsMenu: true
Step 4: The Docker Compose Stack (docker-compose.yml)
Now, we define the unified services to run MongoDB, LiteLLM, and LibreChat together.
version: '3.8'
services:
# 1. Database for LibreChat
mongodb:
image: mongo:6.0
container_name: chatbot-db
restart: unless-stopped
volumes:
- mongo-data:/data/db
networks:
- chatbot-network
# 2. LiteLLM Proxy Gateway
litellm:
image: ghcr.io/berriai/litellm:main-latest
container_name: chatbot-gateway
restart: unless-stopped
volumes:
- ./config.yaml:/app/config.yaml
ports:
- "4000:4000"
command: ["--config", "/app/config.yaml", "--port", "4000", "--detailed_debug"]
environment:
- OPENAI_API_KEY=${OPENAI_API_KEY}
- GEMINI_API_KEY=${GEMINI_API_KEY}
- LITELLM_MASTER_KEY=sk-litellm-dummy-key
extra_hosts:
- "host.docker.internal:host-gateway"
networks:
- chatbot-network
# 3. LibreChat Frontend
librechat:
image: ghcr.io/danny-avila/librechat-dev:latest
container_name: chatbot-ui
restart: unless-stopped
ports:
- "3080:3080"
depends_on:
- mongodb
- litellm
volumes:
- ./librechat.yaml:/app/librechat.yaml
- uploads:/app/client/public/images
environment:
- HOST=0.0.0.0
- PORT=3080
- MONGO_URI=mongodb://mongodb:27017/LibreChat
- JWT_SECRET=${JWT_SECRET}
- CREDS_KEY=${CREDS_KEY}
- CREDS_IV=${CREDS_IV}
- APP_TITLE="Enterprise Private Chat"
- CUSTOM_CONFIG_PATH=/app/librechat.yaml
networks:
- chatbot-network
volumes:
mongo-data:
uploads:
networks:
chatbot-network:
name: chatbot-network
Step 5: Setup Environment Secrets (.env)
Generate the cryptographic secrets required by LibreChat to secure user sessions and encrypt database credentials. Create a .env file in the same directory:
# API Keys (leave blank if running purely local models)
OPENAI_API_KEY=your-openai-api-key-here
GEMINI_API_KEY=your-gemini-api-key-here
# Cryptographic secrets for LibreChat (Replace with random 32-character hex strings)
JWT_SECRET=428bb8fa4d9d19a2e6e3c834a34b22c1
CREDS_KEY=f60db9378c2bd92e85a08332decf8c4d
CREDS_IV=e921d234a90bd71a
Step 6: Booting the Stack
Spin up the entire stack with a single command:
docker compose up -d
Check the running containers to verify everything initialized successfully:
docker compose ps
You should see all three services (chatbot-db, chatbot-gateway, and chatbot-ui) in the Up state.
Accessing Your Chatbot
- Open your browser and navigate to
http://localhost:3080. - Click Sign Up to register the administrator account (the first registered account automatically gains admin privileges).
- Select LiteLLM Gateway from the model selection dropdown.
- Choose your model (e.g.
local-llama3) and start chatting privately!
Conclusion
By deploying LibreChat and LiteLLM on Docker, you give your team access to a state-of-the-art conversational interface while retaining full control over your data. Adding new models is as simple as updating LiteLLM’s config.yaml and restarting the container.
Ready to build more local automations? Explore our guide to serving open-source LLMs locally on CPU and building localized document extraction pipelines.
