Identity verification (Know Your Customer or KYC) is a critical compliance check in fintech, travel, healthcare, and sharing-economy platforms. Extracting data from identity documents—such as passports and driver's licenses—typically requires chaining multiple complex systems: document classification, specialized OCR, key-value extraction, and custom validation heuristics.
Chaining these systems in a robust, stateful manner is challenging. Documents might be uploaded upside down, suffer from low lighting, or turn out to be completely incorrect document types.
By combining the native multimodal vision capabilities of **Google Gemini** with **LangGraph** (a framework for building stateful, multi-actor applications), we can build an automated **KYC Document Processing Pipeline**.
This pipeline classifies uploaded identity documents, routes them to document-specific extraction nodes, performs validation audits (checking for expiration dates), and outputs verified identity structures.
This tutorial guides you through building this system using LangGraph, Gemini, FastAPI, uv, and Docker Compose.
---
## Stateful Workflow Pipeline Design
Traditional linear workflows break down when processing complex, variable documents. By utilizing LangGraph, we can represent our KYC process as a stateful, directed graph that supports conditional routing:
```
+-------------------+
| [ Upload Doc ] |
+---------+---------+
|
+----------v-----------+
| Node: Classify Doc |
+----------+-----------+
|
(Is Passport? / Is License?)
|
+------------------+------------------+
| |
+---------v----------+ +---------v----------+
| Node: Ext Passport | | Node: Ext License |
+---------+----------+ +---------+----------+
| |
+------------------+------------------+
|
+----------v-----------+
| Node: Validate KYC |
+----------+-----------+
|
+--------v--------+
| [ Final State ]|
+-----------------+
```
The pipeline state is maintained in a centralized state class (`KYCState`) as it transitions between nodes.
---
## Step 1: Defining KYC State & Extraction Schemas
Create the schemas in `app/kyc_schemas.py`:
```python
from pydantic import BaseModel, Field
from typing import Optional, List
from enum import Enum
class DocumentType(str, Enum):
PASSPORT = "passport"
LICENSE = "driver_license"
UNKNOWN = "unknown"
# Structured extraction schema for Passports
class PassportDetails(BaseModel):
passport_number: str = Field(..., description="Unique passport identifier")
given_names: str = Field(..., description="First and middle names")
surname: str = Field(..., description="Last name or family name")
date_of_birth: str = Field(..., description="Birthdate formatted as YYYY-MM-DD")
nationality: str = Field(..., description="Country of citizenship")
expiry_date: str = Field(..., description="Expiration date formatted as YYYY-MM-DD")
mrz_code: Optional[str] = Field(None, description="Machine-readable zone text at bottom")
# Structured extraction schema for Driver's Licenses
class LicenseDetails(BaseModel):
license_number: str = Field(..., description="Unique license identifier")
full_name: str = Field(..., description="Full name of licensee")
date_of_birth: str = Field(..., description="Birthdate formatted as YYYY-MM-DD")
expiry_date: str = Field(..., description="Expiration date formatted as YYYY-MM-DD")
license_class: Optional[str] = Field(None, description="Class of vehicles permitted (e.g. 'Class C')")
address: Optional[str] = Field(None, description="Physical address listed on license")
# The shared state dictionary representing LangGraph transactional context
class KYCState(BaseModel):
image_bytes: bytes = Field(..., description="Uploaded raw document image")
media_type: str = Field(..., description="MIME type of the image")
document_type: DocumentType = DocumentType.UNKNOWN
passport_data: Optional[PassportDetails] = None
license_data: Optional[LicenseDetails] = None
is_valid: bool = False
validation_errors: List[str] = Field(default_factory=list)
```
---
## Step 2: Constructing the LangGraph Workflow State Machine
Now we define our processing nodes and orchestrate them using LangGraph. We use Pydantic AI agents internally inside the nodes to perform the targeted extraction using `google-gla:gemini-2.5-flash`.
Create `app/kyc_workflow.py`:
```python
from typing import Dict, Any, Literal
from langgraph.graph import StateGraph, END
from pydantic_ai import Agent, BinaryContent
from datetime import datetime
from app.kyc_schemas import KYCState, DocumentType, PassportDetails, LicenseDetails
# 1. Initialize Pydantic AI Agents
classifier_agent = Agent(
model="google-gla:gemini-2.5-flash",
result_type=DocumentType,
system_prompt=(
"You are an identity document classification expert. "
"Analyze the provided image and classify if it is a passport, "
"a driver_license, or unknown."
)
)
passport_extractor = Agent(
model="google-gla:gemini-2.5-flash",
result_type=PassportDetails,
system_prompt=(
"You are a passport parsing specialist. "
"Extract all details from the passport image into the structured schema."
)
)
license_extractor = Agent(
model="google-gla:gemini-2.5-flash",
result_type=LicenseDetails,
system_prompt=(
"You are a driver's license parsing specialist. "
"Extract all details from the driver's license image into the structured schema."
)
)
# 2. Define Graph Nodes
async def classify_document_node(state: KYCState) -> Dict[str, Any]:
"""Classifies the uploaded image document type."""
result = await classifier_agent.run(
[
"Classify this identity document image.",
BinaryContent(data=state.image_bytes, media_type=state.media_type)
]
)
return {"document_type": result.output}
async def extract_passport_node(state: KYCState) -> Dict[str, Any]:
"""Extracts passport metadata from the image."""
result = await passport_extractor.run(
[
"Extract structured passport details from this image.",
BinaryContent(data=state.image_bytes, media_type=state.media_type)
]
)
return {"passport_data": result.output}
async def extract_license_node(state: KYCState) -> Dict[str, Any]:
"""Extracts license details from the image."""
result = await license_extractor.run(
[
"Extract structured license details from this image.",
BinaryContent(data=state.image_bytes, media_type=state.media_type)
]
)
return {"license_data": result.output}
async def validate_kyc_node(state: KYCState) -> Dict[str, Any]:
"""Audits the extracted metadata checking for expiration limits."""
errors = []
is_valid = True
current_date = datetime.utcnow().date()
expiry_str = None
if state.document_type == DocumentType.PASSPORT and state.passport_data:
expiry_str = state.passport_data.expiry_date
elif state.document_type == DocumentType.LICENSE and state.license_data:
expiry_str = state.license_data.expiry_date
if expiry_str:
try:
expiry_date = datetime.strptime(expiry_str, "%Y-%m-%d").date()
if expiry_date < current_date:
is_valid = False
errors.append(f"Document has expired on {expiry_str}")
except Exception:
is_valid = False
errors.append(f"Invalid date format: {expiry_str}")
else:
is_valid = False
errors.append("No valid expiration date could be found on the document.")
return {"is_valid": is_valid, "validation_errors": errors}
# 3. Define Routing Logic
def route_by_document_type(state: KYCState) -> Literal["passport", "driver_license", "unknown"]:
"""Conditional router mapping document classification to extraction nodes."""
if state.document_type == DocumentType.PASSPORT:
return "passport"
elif state.document_type == DocumentType.LICENSE:
return "driver_license"
return "unknown"
# 4. Build the LangGraph Workflow
workflow = StateGraph(KYCState)
# Add Node definitions
workflow.add_node("classify", classify_document_node)
workflow.add_node("extract_passport", extract_passport_node)
workflow.add_node("extract_license", extract_license_node)
workflow.add_node("validate", validate_kyc_node)
# Configure Entry Point
workflow.set_entry_point("classify")
# Configure Conditional Routing
workflow.add_conditional_edges(
"classify",
route_by_document_type,
{
"passport": "extract_passport",
"driver_license": "extract_license",
"unknown": END
}
)
# Connect remaining edges
workflow.add_edge("extract_passport", "validate")
workflow.add_edge("extract_license", "validate")
workflow.add_edge("validate", END)
# Compile Workflow Graph
kyc_pipeline = workflow.compile()
```
---
## Step 3: Setting Up the FastAPI Gateway
Create `app/kyc_main.py`:
```python
import os
from fastapi import FastAPI, HTTPException, UploadFile, File
from fastapi.middleware.cors import CORSMiddleware
from fastapi.staticfiles import StaticFiles
from fastapi.responses import FileResponse
from app.kyc_schemas import KYCState, DocumentType
from app.kyc_workflow import kyc_pipeline
app = FastAPI(
title="Stateful KYC Pipeline Hub",
version="1.0.0"
)
app.add_middleware(
CORSMiddleware,
allow_origins=["*"],
allow_credentials=True,
allow_methods=["*"],
allow_headers=["*"]
)
ALLOWED_IMAGES = {"image/jpeg", "image/png", "image/webp"}
@app.post("/api/v1/kyc/verify")
async def verify_identity_document(file: UploadFile = File(...)):
"""
KYC document verification pipeline.
Runs LangGraph workflow asynchronously, returning state verification maps.
"""
if file.content_type not in ALLOWED_IMAGES:
raise HTTPException(
status_code=400,
detail=f"Unsupported format: {file.content_type}. Use JPEG, PNG, or WebP."
)
try:
image_bytes = await file.read()
# Initialize Graph State
initial_state = KYCState(
image_bytes=image_bytes,
media_type=file.content_type
)
# Execute Graph Workflow Pipeline
final_state = await kyc_pipeline.ainvoke(initial_state)
# Prepare clean response schema payload
response = {
"document_type": final_state.document_type.value,
"is_valid": final_state.is_valid,
"validation_errors": final_state.validation_errors,
"extraction_results": None
}
if final_state.document_type == DocumentType.PASSPORT:
response["extraction_results"] = final_state.passport_data.model_dump() if final_state.passport_data else None
elif final_state.document_type == DocumentType.LICENSE:
response["extraction_results"] = final_state.license_data.model_dump() if final_state.license_data else None
return response
except Exception as e:
raise HTTPException(status_code=500, detail=f"Pipeline execution failed: {str(e)}")
# Serve static pages
app.mount("/static", StaticFiles(directory="app/static"), name="static")
@app.get("/")
async def read_root():
return FileResponse("app/static/kyc.html")
```
---
## Step 4: High-Fidelity shadcn-ui Dashboard
Create `app/static/kyc.html`:
```html
Rogue Verify — KYC Pipeline
Rogue Verify
Stateful KYC Dashboard
Identity Document Image
Active Workflow Pipeline States
1
Document Classification
3
Validity Compliance Auditing
Extracted Metadata Verification
N/A
Unprocessed
Upload an identity document scan and run the LangGraph pipeline to verify credentials.
